Power-off Cable Identifier

Function: Cable identification, voltage test. Power-off cable identifier is used to identify a particular cable during power cable laying, transfer, maintenance, and fault location, featured with accurate, fast, simple operation and wide application, light weight, compact structure, and strong anti-interference ability.

Features
Technical Specification

function

Cable identification, voltage test

Power

Rechargeable   Li-battery:transmitter: 11.1V;receiver 7.4V,working 8h

Display

Rest voltage display on LCD ;receiver 3.5inch, Electronic dial, dynamic grating

Pulse volt

500V

Pulse Am

30A  Max(Depending on the resistance of the loop)

Pulse Fre

1time/sec

Pulse w

Width: 2ms

Range v

AC 0.00V~600V(50Hz/60Hz)

resolution

AC 0.01V

Coil ID

Flexible coil ID:φ200mm

Length

Crocodile clamp test line 3 meters; test line 1 meter

Signal

Transmitting signal: dynamic display of bar chart

cable identification: clockwise dynamic indication of green grating
non-target cable:counterclockwise dynamic indication of red-orange grating

Gain

6class, press left / right to adjust Gain,

Size

Transmitter:320mm×275mm×145mm;receiver:207mm×101mm×45mm

weight

Transmitter:2.5kg;receiver:540g(with flexible coil);total:3.3 kg

size

LWH: 400mm×245mm×335mm

Charger

Transmitter: 12.6V;receiver: 9V

Anti-volt

Transmitter AC 3700V/rms;receiver: AC 2000V/rms(outer two points)

configuration

Transmitter 1pcs;receiver 1pcs;flexible 1pcs;bag 1pcs;Crocodile clamp test line 2pcs

Testing line 2pcs;charger 2pcs;Li-battery 2pcs(within meters);manual operation 1 pcs
